Code Reader RCD-AI100-SH06W
| Ürün Kodu : | RCD-AI100-SH06W |
| Kategori : | Görsel kontrol ve tanımlama, Kod okuyucular |
| Etiketler : | RCD-AI100-SH06W |
| Stok : | Stokta Var |
| Model | RCD-AI100-SH06W |
| Working principle | CMOS |
| Enclosure type | Square |
| Detection Range | 30~300mm |
| Field of View | Max. 192mm*120mm(@300mm distance) |
| Focal Length | 6mm |
| Focus Adjustment Method | Manual focusing |
| Resolution | 1280×800 |
| Light Source | Unbiased white light |
| Code Type | One-dimensional Code: Code 39, Code93, Code128, EAN-8, EAN-13, Interleaved 2 of 5, UPC, Pharmacode; QR code: QR code, DataMatrix |
| Color/black And White | black and white |
| Shutter | Overall |
| Indicator light | Location indication: 2 green light points indicate the scanning location center area; Status indication: 3 status leds and buzzes |
| Image Sensor Size | 3μm×3μm |
| Target Surface Size | 1/4" |
| Maximum Reading Speed | 60 per second |
| Exposure Time | 20μs~1sec |
| Gain | 0dB~255dB |
| Operating Voltage | 24VDC |
| Power Consumption | 5W |
| Output type | Input control: two optocoupler isolated input, support NPN, PNP type; Output control: three non-isolated output |
| Communication Protocol | TCP Server,TCP Client, ModBus TCP, ModBus RTU, Profinet, Ethernet/IP,MELSEC/SLMP, Fins, Serial |
| Communication Interface | RS232, Ethernet |
| Operating temperature | 0~45℃ |
| Storage Temperature | -20-70℃ |
| Humidity | 5% to 95%RH(non-condensing) |
| Protection level | IP67 |
| Connection Method | Cable connection |
| Dimensions | 47x25x43mm |
| Weight | About 100g |
| Accessories | Cable: M12-17PIN cable Power: 24V power adapter (optional) L-shaped mounting bracket + screws |
