Flat Type CQ07-08NO
| Ürün Kodu : | CQ07-08NO |
| Kategori : | Algılama sensörleri, Kapasitif sensörler |
| Etiketler : | CQ07-08NO |
| Stok : | Stokta Var |
| Model | CQ07-08NO |
| Working principle | Capacitive sensor |
| Housing | Flat blocks |
| Sensing distance | 8mm |
| Detected objects | Metal, liquid, powder, wood, paper, plastic and other materials |
| Indicator | Operating status: LED |
| Sensing range adjustment | Available |
| Switching output | Normally open |
| Output Mode | NPN |
| External input | None |
| Switching frequency | 0.035 kHz |
| Repeatability | 1% |
| Operating Voltage | 10~30V DC±10% |
| Current Consumption | ≤10mA |
| Residual Voltage | 1.5 V or less |
| Load Current | ≤150mA |
| Leakage Current | < 0.01 mA |
| Insulation Resistance | ≥50MΩ (500VDC) between power terminal and housing |
| Dielectric strength | 1000VAC (50/60Hz), 1 minute between the power terminal and housing |
| Vibration Resistance | 10 to 55Hz, amplitude 1.5mm, X/Y/Z axis, 2 hours each |
| Circuit Protection | Reverse polarity protection/short circuit protection/surge protection |
| Operating temperature | -10~55℃ |
| Operating humidity | 35 to 85% relative humidity |
| Enclosure rating | IP66 |
| Connection type | 2m/3 wire cable |
| Dimension | 48.8x20.0x7.0mm |
| Material | Plastic |
| Weight | 0.05kg |
| Installation type | Flush |
| Hysteresis | 10% |
