Ürün Kodu : | CQ07-10PC |
Kategori : | Algılama sensörleri, Kapasitif sensörler |
Etiketler : | CQ07-10PC |
Stok : | Stokta Var |
Model | CQ07-10PC |
Working principle | Capacitive sensor |
Housing | Flat blocks |
Sensing distance | 10mm |
Detected objects | Metal, liquid, powder, wood, paper, plastic and other materials |
Indicator | Operating status: LED |
Sensing range adjustment | Available |
Switching output | Normally closed |
Output Mode | PNP |
External input | None |
Switching frequency | 0.1 kHz |
Repeatability | 5% |
Operating Voltage | 24V DC±10% |
Current Consumption | ≤10mA |
Residual Voltage | 1.5 V or less |
Load Current | ≤50mA |
Leakage Current | < 0.01 mA |
Insulation Resistance | ≥50MΩ (500VDC) between power terminal and housing |
Dielectric strength | 1000VAC (50/60Hz), 1 minute between the power terminal and housing |
Vibration Resistance | 10 to 55Hz, amplitude 1.5mm, X/Y/Z axis, 2 hours each |
Circuit Protection | Reverse polarity protection/short circuit protection/pulse overvoltage protection |
Operating temperature | -30~75℃ |
Operating humidity | 35~85% |
Enclosure rating | IP67 |
Connection type | 2m/3 wire cable |
Dimension | 50.6x30.3x7.0mm |
Material | Plastic |
Weight | 0.05kg |
