Yeni
High Precision Cylindrical Sensor MR-C6-N
| Ürün Kodu : | MR-C6-N |
| Kategori : | Algılama sensörleri, Silindir sensörleri |
| Etiketler : | MR-C6-N |
| Stok : | Stokta Var |
| Model | MR-C6-N |
| Magnetic Sensitivity | 2.5~3.5mT |
| Output Current | ≤12mA |
| Characteristic | Built-in indicator |
| Working Distance | 5~24V DC |
| Detectable Magnetic Poles | N pole |
| Response Time | 5μs |
| Output Method | NPN normally open(N.O.)(ON when approaching) |
| Current Consumption | ≤12mA |
| Insulation Voltage | AC1000V 1minute |
| Insulation Resistance | 250V DC≥20MΩ |
| Ambient Temperature | -20℃~+85℃,no freezing |
| Ambient Humidity | 20%~95%RH,no condensation |
| Material | GF reinforced PBT: black |
| Protection Degree | IP67 |
| Outgoing Line | 1M/3 core cable |
| Applicable Groove Type | T Type |
| Indicator | Red |
