| Model |
ELE-B35PS02 |
| Working principle |
Photoelectric sensor |
| Housing style |
Square |
| Optical working principle |
Background suppressed diffuse reflection |
| Detection Range |
20~400mm |
| Light Source |
Red laser, 650nm (modulated) Class 2 |
| Spot Size |
About Ø1.5mm/400mm |
| Detected Object |
Ø 0.5 mm |
| Indicator light |
Work indicator light: green; Output indicator: red |
| Sensitivity Adjustment |
6 turns potentiometer |
| Switch Mode |
L.on (light entry action) /D.on (light blocking action) can be switched |
| Output Mode |
PNP open collector |
| Response Time |
≤1.2ms |
| Hysteresis |
≤5% |
| Operating Voltage |
10~30V DC±10% |
| Current Consumption |
≤20mA |
| Residual Voltage |
< 1.5 V |
| Load Current |
100mA |
| Insulation Resistance |
≥20MΩ (250V DC) |
| Withstand Voltage |
1000VAC (50/60Hz) |
| ProtectiOn Circuit |
Power supply reverse polarity protection/short circuit protection |
| Operating temperature |
-10~55℃(without freezing) |
| Storage Temperature |
-30~70℃(no freezing) |
| Operating humidity |
35~85%RH (no condensation) |
| Storage Humidity |
35~95%RH(no condensation) |
| Ambient light |
Incandescent lamp ≤1000 Lux; LED lamp ≤600 Lux; Sunlight ≤20000Lux |
| Vibration Resistance |
10~55Hz, amplitude 1.5mm, X, Y, Z axis, 2 hours each |
| Protection rating |
IP65 |
| Maximum Tightening Torque |
0.5 Nm or less |
| Connection Method |
2M/ 4-core cable |
| Dimensions |
11.0 x31.0 x20.0 mm |
| Material |
PBT+ glass fiber (shell); PMMA(lens) |
| Weight |
Approx. 68g |
| Accessories |
Bracket, screws |
