Ürün Kodu : | PTE-RM3AN |
Kategori : | Algılama sensörleri, Fotosel sensörler |
Etiketler : | PTE-RM3AN |
Stok : | Stokta Var |
Model | PTE-RM3AN |
Working principle | Photoelectric sensor |
Housing style | Square |
Optical working principle | Regression reflex |
Detection Range | 3m |
Spot Size | At 2m: 4cm x 4cm |
Detected Object | 18mm |
Light Source | Red LED 660nm (modulated) |
Indicator light | Working indicator light: green; Action light: red |
Sensitivity Adjustment | Single-turn potentiometer |
Switch Mode | L.on (light entry action) /D.on (light blocking action) can be switched |
Output Mode | NPN open collector |
Response Time | ≤1ms |
Switching frequency | 500Hz |
Operating Voltage | 10~30V DC |
Current consumed | ≤21mA |
Residual Voltage | < 1.5V (load current ≤100mA) |
Load Current | ≤100mA |
Insulation Resistance | 20 m Ω |
Withstand Voltage | 0.1 mA (1000 vac) |
ProtectiOn Circuit | Reverse polarity protection/surge protection/short circuit protection |
Operating temperature | -25~55℃(without freezing) |
Storage Temperature | -30~+70℃ |
Operating humidity | 35~85%RH (no condensation) |
Storage Humidity | 35~95%RH |
Ambient light | Incandescent lamp ≤3000 Lux; Sunlight exposure ≤ 10,000 Lux |
Vibration Resistance | 10~50Hz, 0.5mm amplitude, 2 hours in each direction X, Y and Z |
Protection rating | IP67 |
Maximum Tightening Torque | 0.5 Nm or less |
Connection Method | 2M/ 3-core cable 4mm diameter |
Dimensions | 20.0 x31.0 x11.0 mm |
Material | PBT |
Weight | 0.050 kg |
Accessories | Screwdriver, bracket, screws and nuts |
