Triangulation type sensor MLD25-200PV
| Ürün Kodu : | MLD25-200PV |
| Kategori : | Mesafe sensörleri, Lazer mesafe sensörleri |
| Etiketler : | MLD25-200PV |
| Stok : | Stokta Var |
| Model | MLD25-200PV |
| Working principle | Triangulation |
| Housing | square |
| Optical working principle | Diffuse reflection |
| Reference distance | 200mm |
| Measuring Range | 120-280mm |
| Light Source | Red semiconductor laser wavelength: 655nm 1mW Class2 |
| Spot Size | Φ 140 microns |
| Switching mode | L.on/D.on mode/key /RS-485 switch |
| Output Mode | Switching quantity (PNP)/analog quantity (voltage 0~5V/ current 4~20mA) /RS-485 output |
| Response Time | < 10ms/5ms/1.5ms |
| Linearity | ±0.2% F.S. |
| Repeatability | 200um |
| Temperature Drift Characteristics | 0.03%/℃ F.S. |
| Operating Voltage | 12~24V DC±10% |
| Current Consumption | < 40mA at 24V and < 80mA at 12V |
| Load Current | ≤100mA |
| Insulation sesistance | > 500MΩ (500V DC) |
| Dielectric strength | < 0.1mA (when 1000V AC) |
| Operating temperature | -10~+45℃(without freezing) |
| Operating humidity | 35~85%RH (no condensation) |
| Ambient Illumination | Sunlight: ≤10000 lux without interference; Incandescent lamp: ≤3000 lux |
| Vibration Resistance | 10~55Hz sweep frequency, 1.5mm amplitude, X, Y, Z three directions for 2 hours each |
| Enclosure rating | IP67 |
| Connection type | 7 core composite cable, 2m long |
| Dimension | 20x28x45mm |
| Material | Body shell: die-cast aluminum; Front cover: acrylic base |
| Weight | 90g |
| Accessories | Cable |
